VFL-650-1 Pen-Type Visual Fault Locator


Product Overview

This Pen-type VFL is specially designed for field personnel who need an efficient and economical tool for fiber tracing, fiber routing and continuity checking in optical networks. It finds breakpoints, poor connections, bending or cracking in fiber optic cables; and it can find faults in an OTDR dead zone and is used for end-to-end visual fiber identification.

 Applications

Maintenance in telecom , CATV

Test Lab of optical fibers

fiber routing and continuity checking in optical networks.

Other fiber optic measurements

 Features – Pen-Type Visual Fault Locator

2.5mm universal connector, for 1.25mm connectors, FC (Male)-LC. (Female) convertor can be provided on request

Operates either in CW or Pulsed mode with constant output power

Low battery warning

Long battery life (up to 60 hours)

drop-resistand and dust-proof design of laser head

Laser case ground design prevents ESD damage

Portable and rugged

Easy to use

 Technical Specifications

Model VFL-650-1
Central wavelength 650nm±10nm (635nm is available on request)
Emitter type FP-LD (Perot laser diode)
Output power Optional choice for 5mw, 10mw,20mw
Optical connector 2.5mm universal connector, for 1.25mm connectors, FC (Male)-LC. (Female) convertor can be provided on request
Operating model Both CW and Pulse available
Pulse frequency 2Hz to 3Hz
Power supply 2AA alkaline batteries
Battery  LR6 AA alkaline battery
Operating temperature -20°C to 60°C
Storage temperature -40°C to 85°C
Dimension Φ23 X 183

 Standard Packages – Pen-type Visual Fault Locator

Model Includes
VFL-650-1 Main unit, User Manual

 Order Information

MODEL SPECIFICATION
VFL-650-1-5 Output power: 5mw, Laser range: ≥5KM
VFL-650-1-10 Output power: 10mw, Laser range: ≥10KM
VFL-650-1-20 Output power: 20mw, Laser range: ≥20KM
